Description

– 250Watts with a large power reserve
– Capable of handling 70V, 25V, 8-ohm, and 4-ohm speaker loads
– 8 module bays
– Wide selection of advanced plug-in modules
– 2 module bays capable of handling signal processing plug-in output modules
– 4 levels of priority between modules
– 11-segment LED output level meter monitors the output level of the power amplifier, with Peak and Average meter switch
– Motorized master volume control that can be remotely operated
– Bass and treble controls
– Two-color LED for each channel indicates input active/clipping
– Lockable switch permits user to select either transformer-coupled outputs or a direct lowimpedance output
– Master mute function overrides all audio from the mixer section of the amplifier
– Bass and treble control bypass switch
– 125 Hz Lo-cut feature
– Signal processing insert jacks allow external equipment to be inserted between the preamp output and the power amp input
– Pre-EQ unbalanced buffer output signal “post” all unit controls, but “pre” any external signal processing equipment connected
– Grounded convenience receptacle
– Available security cover with break-away tabs
– 2 rack spaces high (3-1/2″)
– UL/cUL listed
