Description

– Meet TIA/EIA TSB-40; ANSI/TIA/EIA-568-C.2
– Category 6
– Module type: RJ-45 (8P8C)
– Termination type: vertical type at 90 degrees – 110 type tool/ KJNE-TOOL
– Pins: 110 IDC
– RJ-45 housing: high-impact ABS plastic (UL 94V)
– RJ-45 pins: phosphor bronze with gold plating
– IDC housing: polycarbonate (PC, UL 94V-0)
– IDC pins: Ø 0.45 mm; phosphor bronze with tin plating Insertion
– cap: polybutylene terephthalate, 19% glass (PBT GF) Insertion
– base: polybutylene terephthalate, 30% glass (PBT GF) Wire cap:
– polycarbonate (PC, UL 94V-0)
