Description

– 1 Zone one-way page control enhanced
– Enhanced: Phantom zone allows paging to all speakers but limits music to selected speakers
– Built-in single and warble tone generator
– Background music input with voice operated mute
– Page override for special priority announcements
– Battery back-up input
– Built-in power
– UL listed
– Access: page port, PBX loop-start trunk port, electronic or 1A2 line key (line card required), or dedicated single line phone set
– Input impedance: 600 ohm
– Music source impedance: 4 to 600 ohm
– Music input level: -10dBm nominal
– DC output: -24 Vdc @ 1A
– Power requirements: 230 Vac/.5A
-Weight: 5.3lbs
– Dimensions: 7.01″H x 9″W x 2.4″D
