Description

– 3 Zone one-way page control
– Provides tandem all call
– Background music input, automatically mutes in zonebeing paged
– Page override for special priority announcements
– Features are programmable per zone
– Built-in tone generator for night ringing, time clock tone, doorbell
– Accepts pulse and tone dial
– Battery back-up input
– UL listed
– To interface with analog extension or Centrexline add the VC-V-9970
– Access: page port on selected telephone systems, PBX loop start or ground-start trunk port, electronic or 1A2 line key (line card required), or dedicated single line phoneset
– Input impedance: 600 ohm
– Music sourceimpedance: 4 to 600 ohm
– Music input level: -10dBm nominal
– DC output: -24 Vdc @ 500 mA
– Power requirements: 230 Vac/.5A or 120 Vac/1A
– Weight: 6.25lbs
– Dimensions: 7.1″H x 10″W x 3″D
